Model / Part Number: Type 2000 CLASSIC
Availability subject to quotation and stock confirmationSupplied for maintenance, retrofit and replacement projects. Exact suffix, configuration and condition must be confirmed before ordering.
WhatsApp InquiryResponse within 1 business dayFURUYA DENKI is an independent supplier and is not affiliated with or authorized by the brands shown on this page. Brand names, trademarks and part numbers are used for identification only. Availability, specifications, condition, origin, documentation, lead time and warranty are subject to our formal quotation. Please verify all technical requirements before ordering. Images are for reference only.
| Valve Type | Pneumatically actuated 2/2-way angle seat valve |
|---|---|
| Control Function | Normally Closed (NC) / Normally Open (NO), depending on configuration |
| Valve Body Material | Stainless steel CF3M (316L) or CF8 (304) |
| Seal Material | PTFE; other seal materials available depending on configuration |
| Process Connection | Internal thread, clamp, flange or welded connection |
| Nominal Size | DN 15 to DN 65, depending on configuration |
| Operating Pressure | Up to 25 bar |
| Media Temperature | -10 to +185 °C |
| High Temperature Option | Up to +230 °C |
| Low Temperature Option | Down to -40 °C |
| Actuator Type | Pneumatic piston actuator |
| Actuator Material | PA or PPS |
| Flow Direction | Below seat or above seat, depending on configuration |
| Media | Liquids, gases, steam and compatible process media |
| Accessories | Position indication, stroke limitation and manual override options |
| نوع الصمام | صمام مقعد زاوي هوائي 2/2 |
| وظيفة التحكم | مغلق عادةً (NC) / مفتوح عادةً (NO) حسب التكوين |
| مادة جسم الصمام | فولاذ مقاوم للصدأ CF3M (316L) أو CF8 (304) |
| مادة الإحكام | PTFE، مع مواد إحكام أخرى حسب التكوين |
| وصلة العملية | قلاوظ داخلي، Clamp، فلنجة أو وصلة ملحومة |
| المقاس الاسمي | DN 15 إلى DN 65 حسب التكوين |
| ضغط التشغيل | حتى 25 bar |
| درجة حرارة الوسط | -10 إلى +185 °C |
| خيار درجات الحرارة العالية | حتى +230 °C |
| خيار درجات الحرارة المنخفضة | حتى -40 °C |
| نوع المشغل | مشغل هوائي مكبسي |
| مادة المشغل | PA أو PPS |
| اتجاه التدفق | أسفل المقعد أو أعلى المقعد حسب التكوين |
| الوسائط | السوائل والغازات والبخار ووسائط العمليات المتوافقة |
| الملحقات | خيارات إظهار الموضع وتحديد الشوط والتشغيل اليدوي |
| Availability & Delivery | Availability subject to quotation and stock confirmation |
|---|---|
| Lead Time | Availability and lead time depend on valve size, body material, process connection, actuator size, control function and sealing material. Please provide the required operating conditions and connection details for current availability and delivery confirmation. |
| Shipping Options | Air freight, sea freight, express |
| Packaging | Secure export packaging |
Bürkert Type 2000 CLASSIC is used for reliable shut-off and flow control of liquids, gases and steam in industrial process applications. It is commonly used in process automation, utility systems and general fluid handling.
Bürkert Type 2000 is a pneumatically actuated 2/2-way angle seat valve. It combines a pneumatic piston actuator with a flow-optimized valve body to provide high flow rates and reliable switching performance.
Depending on the selected configuration, Type 2000 is available with internal thread, clamp, flange and welded process connections.
Yes. Bürkert Type 2000 can be configured for steam and other high-temperature process media. The suitable valve body, seal material, actuator and operating conditions should be confirmed before ordering.
Please provide the medium, operating pressure, temperature, valve size, process connection, control function, actuator requirements and preferred sealing material so that the correct Type 2000 configuration can be selected.
