Model / Part Number: FRS 510
Availability subject to quotation and stock confirmationSupplied for maintenance, retrofit and replacement projects. Exact suffix, configuration and condition must be confirmed before ordering.
WhatsApp InquiryResponse within 1 business dayIndependent supplier; model, suffix, condition and availability require confirmation.
The DUNGS FRS 510 is a spring-loaded Rp 1 gas pressure regulator for maintaining a stable outlet pressure in burners, boilers, furnaces and industrial gas equipment. It supports inlet pressure up to 500 mbar and is supplied as standard with a blue 10–30 mbar outlet-pressure spring.
The DUNGS FRS 510 is a spring-loaded gas pressure regulator with an adjustable setpoint spring for maintaining a constant and stable outlet pressure. It complies with EN 88-1 Class A Group 2 and DIN 3380 and is designed for gas burners, boilers, furnaces and industrial gas equipment.
FRS 510 has an Rp 1 threaded connection and a maximum operating pressure of 500 mbar. The standard factory-installed blue spring provides an adjustable outlet-pressure range of 10–30 mbar. Alternative springs allow other outlet-pressure ranges between 2.5 and 200 mbar.
The regulator incorporates inlet-pressure compensation, a working diaphragm and a safety diaphragm. Outlet-pressure sensing is internal as standard, while an external pulse connection version is also available. G 1/4 pressure connections are provided on both sides.
FRS 510 operates mechanically and requires no electrical power. Confirm the required outlet-pressure range, spring colour, internal or external pulse configuration, gas flow and exact DUNGS order number before quotation or replacement.
| Specification 1 | DUNGS |
|---|---|
| Specification 2 | FRS 510 |
| Specification 3 | Spring-loaded gas pressure regulator |
| Specification 4 | Rp 1 threaded connection |
| Specification 5 | DN 25 |
| Specification 6 | 500 mbar |
| Specification 7 | 50 kPa |
| Specification 8 | From 5 mbar or outlet pressure plus 2.5 mbar up to 500 mbar |
| Specification 9 | 10–30 mbar |
| Specification 10 | Spring 4, blue |
| Specification 11 | 2.5–9, 5–13, 5–20, 25–55, 30–70, 60–110, 100–150 or 140–200 mbar |
| Specification 12 | EN 88-1 Class A Group 2; DIN 3380; RG 10 |
| Specification 13 | Mechanical spring and diaphragm; no electrical power required |
| Specification 14 | Integrated compensation diaphragm |
| Specification 15 | Integrated |
| Specification 16 | Internal pulse as standard; external pulse version optional |
| Specification 17 | G 1/4 ISO 228 on both sides |
| Specification 18 | G 1/4 ISO 228; vent line required only in special cases |
| Specification 19 | -15 to +70 °C |
| Specification 20 | Regulator dome vertically upright through horizontal |
| Specification 21 | Gas families 1, 2 and 3 and other neutral gaseous media |
| Specification 22 | Dry gas containing up to 0.1 vol.% H2S |
| Specification 23 | Aluminium and steel |
| Specification 24 | NBR |
| Specification 25 | 1.2 kg |
| Specification 26 | 070409 |
| Specification 27 | 210381 |
| Specification 28 | 229845 |
| Specification 29 | Confirm spring colour, outlet-pressure range, pulse connection and nameplate order number |
