Model / Part Number: GP10
Availability subject to quotation and stock confirmationSupplied for maintenance, retrofit and replacement projects. Exact suffix, configuration and condition must be confirmed before ordering.
WhatsApp InquiryResponse within 1 business dayFURUYA DENKI is an independent supplier and is not affiliated with or authorized by the brands shown on this page. Brand names, trademarks and part numbers are used for identification only. Availability, specifications, condition, origin, documentation, lead time and warranty are subject to our formal quotation. Please verify all technical requirements before ordering. Images are for reference only.
| Parameter Name | Parameter Value Unit |
|---|---|
| Product Type | PowerTrap Mechanical Pump - |
| Model | GP10 - |
| Series | PowerTrap - |
| Pumped Medium | Steam Condensate / Water - |
| Motive Medium | Saturated Steam / Compressed Air / Nitrogen - |
| Body Material | Cast Iron FC250 / Cast Steel ASTM A216 Gr.WCB - |
| Connection | Screwed / Flanged - |
| Pumped Medium Inlet × Outlet | 3×2 or 2×2 / 3×2 in |
| Motive Medium Inlet | 1 in |
| Pump Exhaust Outlet | 1 in |
| Maximum Operating Pressure | 150 psig |
| Maximum Operating Temperature | 365 °F |
| Maximum Allowable Pressure | 200 / 230 psig |
| Maximum Allowable Temperature | 428 °F |
| Motive Medium Pressure Range | 5–150 psig |
| Maximum Allowable Back Pressure | 7 psi less than motive medium pressure - |
| Volume per Discharge Cycle | Approx. 8 gal |
| Operation | Method Mechanical / No Electricity Required |
| Main Function | Condensate Transfer and Recovery - |
| Application | Open Condensate Recovery / Heat Exchangers / Reboilers / Dryers - |
| اسم المعلمة | قيمة المعلمة الوحدة |
| نوع المنتج | مضخة ميكانيكية PowerTrap - |
| الموديل | GP10 - |
| السلسلة | PowerTrap - |
| السائل المضخوخ | مكثفات البخار / الماء - |
| وسيط التشغيل | بخار مشبع / هواء مضغوط / نيتروجين - |
| مادة الهيكل | حديد زهر FC250 / فولاذ مصبوب ASTM A216 Gr.WCB - |
| نوع التوصيل | ملولب / فلنجة - |
| مدخل × مخرج السائل المضخوخ | 3×2 أو 2×2 / 3×2 in |
| مدخل وسيط التشغيل | 1 in |
| مخرج عادم المضخة | 1 in |
| أقصى ضغط تشغيل | 150 psig |
| أقصى درجة حرارة تشغيل | 365 °F |
| أقصى ضغط مسموح | 200 / 230 psig |
| أقصى درجة حرارة مسموحة | 428 °F |
| نطاق ضغط وسيط التشغيل | 5–150 psig |
| أقصى ضغط خلفي مسموح | أقل من ضغط وسيط التشغيل بمقدار 7 psi - |
| حجم التصريف لكل دورة | حوالي 8 gal |
| طريقة التشغيل | ميكانيكية / لا تحتاج إلى كهرباء - |
| الوظيفة الرئيسية | نقل واستعادة المكثفات - |
| التطبيق | استعادة المكثفات المفتوحة / المبادلات الحرارية / أجهزة إعادة الغليان / المجففات - |
| Availability & Delivery | Availability subject to quotation and stock confirmation |
|---|---|
| Lead Time | Availability and delivery time depend on connection specification, motive medium requirements and order quantity. Please contact us to confirm current stock and delivery schedule. |
| Shipping Options | Air freight, sea freight, express |
| Packaging | Secure export packaging |
The TLV GP10 PowerTrap is used to transfer and recover steam condensate in industrial steam systems, especially where condensate must be lifted or discharged against back pressure.
The GP10 uses steam, compressed air or nitrogen as the motive medium to pressurize the pump chamber and discharge condensate into the return line without an electric motor.
No. The TLV GP10 is mechanically operated and requires no electrical power, making it suitable for reliable condensate recovery in industrial environments.
The GP10 is suitable for condensate collection tanks, heat exchangers, dryers, process equipment, open condensate recovery systems and other industrial steam applications.
Please confirm the GP10 model, connection size and type, condensate load, motive pressure, back pressure, motive medium and installation conditions before ordering.
