Model / Part Number: GT10
Availability subject to quotation and stock confirmationSupplied for maintenance, retrofit and replacement projects. Exact suffix, configuration and condition must be confirmed before ordering.
WhatsApp InquiryResponse within 1 business dayFURUYA DENKI is an independent supplier and is not affiliated with or authorized by the brands shown on this page. Brand names, trademarks and part numbers are used for identification only. Availability, specifications, condition, origin, documentation, lead time and warranty are subject to our formal quotation. Please verify all technical requirements before ordering. Images are for reference only.
| Parameter Name | Parameter Value Unit |
|---|---|
| Product Type | Mechanical Pump with Built-in Steam Trap - |
| Model | GT10 - |
| Series | PowerTrap - |
| Pumped Medium | Steam Condensate - |
| Motive Medium | Saturated Steam - |
| Body Material | Cast Iron FC250 / Cast Steel ASTM A216 Gr.WCB - |
| Connection | Screwed / Flanged - |
| Pumped Medium Inlet | DN80 - |
| Pumped Medium Outlet | DN50 - |
| Motive Medium Inlet | DN25 - |
| Pump Exhaust Outlet | DN25 - |
| Maximum Operating Pressure | 1.05 MPaG |
| Maximum Operating Temperature | 185 °C |
| Motive Medium Pressure Range | 0.03–1.05 MPaG |
| Maximum Allowable Back Pressure | 0.05 MPa below motive medium pressure - |
| Discharge Volume per Cycle | Approx. 30 L |
| Standard Filling Head | 860 mm |
| Minimum Filling Head | 710 mm |
| Operating Method | Mechanical / No Electricity Required - |
| Main Function | Condensate Pumping and Steam Trapping - |
| Application | Heat Exchangers / Reboilers / Dryers / Condensate Recovery - |
| اسم المعلمة | قيمة المعلمة الوحدة |
| نوع المنتج | مضخة ميكانيكية مع مصيدة بخار مدمجة - |
| الموديل | GT10 - |
| السلسلة | PowerTrap - |
| السائل المضخوخ | مكثفات البخار - |
| وسيط التشغيل | بخار مشبع - |
| مادة الهيكل | حديد زهر FC250 / فولاذ مصبوب ASTM A216 Gr.WCB - |
| نوع التوصيل | ملولب / فلنجة - |
| مدخل المكثفات | DN80 - |
| مخرج المكثفات | DN50 - |
| مدخل وسيط التشغيل | DN25 - |
| مخرج عادم المضخة | DN25 - |
| أقصى ضغط تشغيل | 1.05 MPaG |
| أقصى درجة حرارة تشغيل | 185 °C |
| نطاق ضغط وسيط التشغيل | 0.03–1.05 MPaG |
| أقصى ضغط خلفي مسموح | أقل من ضغط وسيط التشغيل بمقدار 0.05 MPa - |
| حجم التصريف لكل دورة | حوالي 30 L |
| ارتفاع التعبئة القياسي | 860 mm |
| أدنى ارتفاع تعبئة | 710 mm |
| طريقة التشغيل | ميكانيكية / لا تحتاج إلى كهرباء - |
| الوظيفة الرئيسية | ضخ المكثفات وتصريف البخار - |
| التطبيق | المبادلات الحرارية / أجهزة إعادة الغليان / المجففات / استعادة المكثفات - |
| Availability & Delivery | Availability subject to quotation and stock confirmation |
|---|---|
| Lead Time | Availability and delivery time depend on connection specification, motive medium requirements and order quantity. Please contact us to confirm current stock and delivery schedule. |
| Shipping Options | Air freight, sea freight, express |
| Packaging | Secure export packaging |
The TLV GT10 PowerTrap is used for condensate recovery and drainage from heat exchangers, reboilers, dryers and other steam-using equipment, especially in systems where stall conditions may occur.
When equipment pressure is higher than the return-line back pressure, the GT10 operates as a steam trap. When pressure becomes too low for natural drainage, it automatically switches to pump operation and forces condensate into the return line.
No. The GT10 operates mechanically using steam or compressed air as the motive medium, so no electrical power supply is required.
The GT10 continues removing condensate even when equipment pressure falls below back pressure, helping reduce condensate accumulation, unstable heating, water hammer and other problems associated with stall.
Please confirm the GT10 model, connection sizes, condensate load, inlet pressure, back pressure, motive medium pressure, motive medium type and installation conditions before ordering.
