Model / Part Number: J6S-X
Availability subject to quotation and stock confirmationSupplied for maintenance, retrofit and replacement projects. Exact suffix, configuration and condition must be confirmed before ordering.
WhatsApp InquiryResponse within 1 business dayFURUYA DENKI is an independent supplier and is not affiliated with or authorized by the brands shown on this page. Brand names, trademarks and part numbers are used for identification only. Availability, specifications, condition, origin, documentation, lead time and warranty are subject to our formal quotation. Please verify all technical requirements before ordering. Images are for reference only.
| Parameter Name | Parameter Value Unit |
|---|---|
| Product Type | Free Float Steam Trap - |
| Model | J6S-X - |
| Body Material | Stainless Steel - |
| Operating Principle | Self-modulating Free Float - |
| Connection Type | Screwed Connection - |
| Nominal Size | DN15 / DN20 / DN25 - |
| Maximum Operating Pressure | Up to 2.1 MPaG |
| Maximum Operating Temperature | 220 °C |
| Air Vent Type | Thermostatic Air Vent - |
| Condensate Discharge | Continuous and Smooth - |
| Valve Mechanism | Free Float Mechanism - |
| Application | Industrial Steam Systems - |
| اسم المعلمة | قيمة المعلمة الوحدة |
| نوع المنتج | مصيدة بخار ذات عوامة حرة - |
| الموديل | J6S-X - |
| مادة الهيكل | الفولاذ المقاوم للصدأ - |
| مبدأ التشغيل | عوامة حرة ذاتية التنظيم - |
| نوع التوصيل | توصيل ملولب - |
| المقاس الاسمي | DN15 / DN20 / DN25 - |
| أقصى ضغط تشغيل | حتى 2.1 MPaG |
| أقصى درجة حرارة تشغيل | 220 °C |
| نوع تنفيس الهواء | تنفيس هواء حراري - |
| تصريف المكثفات | مستمر وسلس - |
| آلية الصمام | آلية العوامة الحرة - |
| التطبيق | أنظمة البخار الصناعية - |
| Availability & Delivery | Availability subject to quotation and stock confirmation |
|---|---|
| Lead Time | Available by order. Please contact us for current stock status and delivery time. |
| Shipping Options | Air freight, sea freight, express |
| Packaging | Secure export packaging |
The TLV J6S-X is designed for continuous condensate drainage from industrial steam systems, process equipment and heating applications. It helps improve steam efficiency by removing condensate reliably.
The TLV J6S-X features a stainless steel body, providing excellent corrosion resistance, durability and reliable performance in industrial steam environments.
The Free Float mechanism automatically adjusts condensate discharge according to the actual load conditions, providing continuous drainage while minimizing steam loss.
The J6S-X is suitable for industrial steam systems, process equipment, heating systems, heat exchangers and applications requiring reliable condensate removal.
Please confirm the model number, operating pressure, steam conditions, connection size and installation requirements before ordering to ensure the correct selection.
